The input voltage: AC220 50/60 hz - 230 - v
Consumed power: 1500 w
Light bulb specifications: HMI 1200 w/S
Size of lamps and lanterns: L500 * H760mm W410
Carton size: L620 * H900mm W605
Air box size: L610 * H910mm W480
53 kg net weight:
Performance characteristics
Display: LCD blue screen, can be very intuitive to set personalization capabilities
Colours: 1 color plate, basic color 7 color + white light half color effect, linear effect, adjustable speed double rainbow effect
Color: CMY (3 colors) combination effect, colour is infinite. CMY. Infinite mixed color system.
Soft light slice, atomization effect. Figure case: rotating pattern plate:
4 + white light design, can replace, the index function, the design of dithering, reversible variable rotation, forward automatically rotate speed
Fixed pattern plate: four design + white light, replaceable, one-way variable speed water effect, pattern dithering
Fixed pattern outside diameter size: 64 mm, fixed pattern size: 54 mm
Rotation pattern outside diameter size: 53 mm, rotating design effective size: 48 mm
Mirror plate edges: white light, a second prism, a four prism, comet prism, gradient lens.
Focus: DMX linear adjustment, dimming: double call light
Stroboscopic: 0.3 ~ 10 times/SEC
Vertical direction of rotation Angle: horizontal 450 °, 270 °
Beam Angle: 13 ~ 24 ° linear adjustment
Control mode: international standard DMX512 signal, 24 control channel
Other facilities: horizontal, vertical, adjustable speed, horizontal and vertical
The light lotus root reset system, after the misoperation accident happen, can automatically retrieve position, good heat dissipation system fully, overheating protection measures
With photoelectric detection, light bubble delay, has protective function to the lamp and control system, improve the stability of lamps and lanterns
Through external console window or lamp before body end plate control, store editor to run the program to the CPU in the body,
Without control table can also be run programming or run a program that can be stored for eight scenes.
Set the security password for the client, can show light bulbs and lamps and lanterns use time
