The technical specifications
12 channel.
Light bulb models: Philips MSD Platinum 5 r or YODN 5 r power: 189 w light flux is 189 lm, color WenKeDa 8500 k.
Four beautiful dot matrix display, light touch switch, reversing 180 ° display.
Color plate: a color plate, each color plate is composed of 14 color piece,
Pattern plate: 14 design effect.
Round effect: a rotating prism, mobile effect, atomization capabilities.
0-100% mechanical dimmer, support mechanical stroboscopic and adjustable speed stroboscopic effect, frequency ShanHong support function.
Lens group of optical system, electric focus, beam Angle 0 ° ~ 4.
Using photoelectric reset system, after the misoperation accident happen, can automatically retrieve reset.
Level 540 °, 8 bit / 16 bit resolution
250 ° vertically, 8 bit / 16 bit resolution.
Overheat protection.
Power supply: 200-240 - v, 50/60 hz
Power: 200 w
IP protection grade: IP20
Inductance ballasts and AC/DC switching power supply.
Size: 523 (length) x 337 (width) x 511 mm (high)
Net weight: 19.5 KG
